PSM-Series Programmable Dual-Range D.C. Power Supplies

PSM-6003 200W Programmable Dual-Range Linear D.C. Power Supply

Features

• Single Output Dual Range Max. 200W • High resolution: 1mV/1mA • 0.01% load/line regulation, 350uVrms ripple • Auto step runing with timer setting and 100 Sets memory • Safety design: OVP,OCP & OTP;Output ON/OFF control • Self-test and software calibration • Highly visible vacuum-fluorescent display • Front and rear output terminal • Standard interface : RS-232C, GPIB • Option : European Jack Type Terminal

Description

The PSM-Series is single output / dual range, 120W or 200W, programmable linear DC power supplies. OVP, OCP, OTP, and, output On/Off control protect the PSM-Series and their loads from unexpected conditions. High resolution, high regulation, and low ripple are maintained at 1mV/1mA, 0.01%, and <350 Vrms, respectively. Operation and configuration is simplified with a digital interface and a clear LCD display. Standard features include store/recall output memories, automatic stepping with timers for continuous testing and self-testing, and software calibration features to reduce maintenance efforts. SCPI programming, LabVIEW drivers, RS-232C, and GPIB interfaces enable easy automated test system integration and remote control. The PSM-Series is an ideal choice for high precision applications such as QA verification and product development.

Accessories

User manual x 1, Power cord x 1, Test lead GTL-104A x 1 , European test lead GTL-204A x 1, Ground lead GTL-201A x 1 (European terminal), Sense lead GTL-202 x 1 (European terminal) Optional Accessories GTL-232 RS-232C Cable, 9-pin Female to 9-pin, Null Modem for PC Computer
