USG-2030 RF signal generator
Frequency Range 2.0 GHz to 3.0 GHz
Output Power -30 dBm to 0 dBm , in 1 dB steps
Internal Reference 25 MHz aging ±1 ppm at first year
Frequency Accuracy ± 2 kHz at 2 GHz, 0 dBm Output
Frequency Resolution 10 kHz
Output Control On / Off
On / Off Isolation ≤ -75 dBc
Mode Control Fixed Frequency / Single Sweep / CW Sweep /
Hopping/Power Sweep
Step Dwell ≤ 1000 ms in 1* ms steps
Frequency Offset -50 kHz to 50 kHz in 10 kHz steps
Accuracy
Output Flatness ± 1 dB, ref. to at 0 dBm Output
2500MHz
Phase noise < -93 dBc/Hz 10 kHz offset @ 2.5 GHz
< -100 dBc/Hz 100 kHz offset @ 2.5 GHz
2nd Harmonics 0 dB Attenuation
≤ -30 dBc, typical 2.0 GHz to 3.0 GHz,
fundamental
3rd Harmonics 0 dB Attenuation
≤ -45 dBc, typical 2.0 GHz to 3.0 GHz,
fundamental
Spurious related to
Resolution settings
(Single Point Mode)
Spurious related to the
fundamental output
