USG-0103 RF signal generator

• Frequency Range 100 MHz to 300 MHz
• Output Power -30 dBm to 0 dBm ,in 1 dB steps
• Internal Reference 25 MHz aging ±1 ppm at first year
• Frequency Accuracy ± 100 Hz at 100MHz, 0 dBm Output
• Frequency Resolution 10 kHz
• Output Isolation ≤ -75 dBc Output Control On / Off
• Mode Control Fixed Frequency / Single Sweep / CW Sweep /
• Hopping/power sweep
• Step Dwell ≤ 1000 ms in 1* ms steps
• Frequency Offset -50 kHz to 50 kHz in 10 kHz steps
• Output Flatness -1 dBm~-2dbm,
• ( typical )
• Phase noise < -100 dBc/Hz,
• typical
• 10 kHz offset @ 200 MHz
• < -110 dBc/Hz 100 kHz offset @ 200 MHz
• 2nd Harmonics 0 dB Attenuation
• ≤ -45 dBc, typical > 100 MHz, fundamental
• 3rd Harmonics 0 dB Attenuation
• ≤ -7dBc, typical ≤ 150 MHz, fundamental
• ≤ -35 dBc, typical > 150 MHz, fundamental
• Spurious related to
• Resolution settings
• (Single Point Mode)
• Spurious related to the
• fundamental output
• ≤ -30 dBc, typical Resolution < 1 MHz
• ≤ -65 dBc, typical Resolution ≥ 1 MHz
• ≤ -60 dBc, typical
