USG-0818 RF signal generator

• Frequency Range 800 MHz to 1.8 GHz
• Output Power -30 dBm to 0 dBm in 1 dB steps
• Internal Reference 25 MHz aging ±1 ppm at first year
• Frequency Accuracy ± 800 Hz at 800MHz, 0 dBm Output
• Frequency_Resolution 10 kHz
• Output Control On / Off
• On / Off Isolation ≤ -75 dBc
• Mode Control Fixed Frequency / Single Sweep / CW Sweep /
• Hopping/power sweep
• Step Dwell ≤ 1000 ms in 1* ms steps
• Frequency Offset -50 kHz to 50 kHz in 10 kHz steps
• Accuracy typical
• Output Flatness -1dBm~-0.5dBm (O dBm output Level)
• Phase noise < -97 dBc/Hz 10 kHz offset @ 1.3 GHz
• < -102 dBc/Hz 100 kHz offset @ 1.3 GHz
• 2nd Harmonics 0 dB Attenuation
• ≤ -25 dBc, typical >800 MHz, fundamental
• 3rd Harmonics 0 dB Attenuation
• ≤ -25 dBc, typical ≤900 MHz, fundamental
• ≤ -35 dBc, typical >900 MHz, fundamental
• Spurious related to Resolution settings (Single Point Mode) Spurious related to the
• fundamental output
• ≤ -30 dBc, typical Resolution < 1 MHz
• ≤ -65 dBc, typical Resolution ≥ 1 MHz
• Spurious related to the fundamental output
• ≤ -65 dBc, typical
