USG-2030 RF signal generator

• Frequency Range 2.0 GHz to 3.0 GHz
• Output Power -30 dBm to 0 dBm , in 1 dB steps
• Internal Reference 25 MHz aging ±1 ppm at first year
• Frequency Accuracy ± 2 kHz at 2 GHz, 0 dBm Output
• Frequency Resolution 10 kHz
• Output Control On / Off
• On / Off Isolation ≤ -75 dBc
• Mode Control Fixed Frequency / Single Sweep / CW Sweep /
• Hopping/Power Sweep
• Step Dwell ≤ 1000 ms in 1* ms steps
• Frequency Offset -50 kHz to 50 kHz in 10 kHz steps
• Accuracy
• Output Flatness ± 1 dB, ref. to at 0 dBm Output
• 2500MHz
• Phase noise < -93 dBc/Hz 10 kHz offset @ 2.5 GHz
• < -100 dBc/Hz 100 kHz offset @ 2.5 GHz
• 2nd Harmonics 0 dB Attenuation
• ≤ -30 dBc, typical 2.0 GHz to 3.0 GHz,
• fundamental
• 3rd Harmonics 0 dB Attenuation
• ≤ -45 dBc, typical 2.0 GHz to 3.0 GHz,
• fundamental
• Spurious related to
• Resolution settings
• (Single Point Mode)
• Spurious related to the
• fundamental output
